Number of products found: 3

Product number
Stock
Quantity
Uom
Shop
Unit price from
Type Model Flowrate Medium Max. pressure Grease outlet thread Grease inlet thread Design Connection air Controls Nozzle diameter
Yes
pc
on request
Volumetric Metering Valve
AXDV-C3
0,1 - 2,0 cm3
up to NLGI class 3
200 bar
R 1/8"
R 1/4"
Standard
M3 for hose ø 4/2 mm
pneumatic/pressure controlled
Metering valve AXDV-C3,

Metering valve AXDV-C3,

0.1 - 2.0 cm3 (V3.0)

Go to product

No
pc
on request
Volumetric Metering Valve
AXDV-C3-HG
0,1 - 2,0 cm3
up to NLGI class 3
200 bar
R 1/8"
R 1/4"
Handgrip Horizontal
M5 for tube ø 6/4 mm
pneumatic/pressure controlled
Metering valve AXDV-C3-HG,

Metering valve AXDV-C3-HG,

Metering rage 0.1-2.0ccm,

Handgrip horizontal (V3.0)

Go to product

No
pc
on request
Volumetric Metering Valve
AXDV-C3-SV
0,1 - 2,0 cm3
up to NLGI class 3
200 bar
R 1/8"
R 1/4"
Handgrip Vertical
M5 for tube ø 6/4 mm
pneumatic/pressure controlled
Metering valve AXDV-C3-SV,

Metering valve AXDV-C3-SV,

Metering rage0.1-2.0cm3,

Handgrip vertical (V2.0)

Go to product

The listed prices are without VAT and apply to the quantity that is currently in stock
