PRODUCTS HENNLICH
Products CEMA-TECH

Metering Valves AXDV-C1

SHOW PRODUCTS
INQUIRY

Number of products found: 4

Product number
Stock
Quantity
Uom
Shop
Unit price from
Type Model Flowrate Medium Max. pressure Grease outlet thread Grease inlet thread Design Connection air Controls Nozzle diameter

Z-AC-0008528 Metering valve AXDV-C1-LP-G1/8 (V3.0) 3 - 20 mm3

No
pc
on request
Volumetric Metering Valve
AXDV-C1-LP-G1/8
3 - 20 mm3
up to NLGI class 3
20 bar
R 1/8" / With dosing needle adapter R 1/8''
R 1/8"
Standard
M2,5 for hose ø 4/2 mm
pneumatic/pressure controlled
Metering valve AXDV-C1-LP-G1/8 (V3.0)

Metering valve AXDV-C1-LP-G1/8 (V3.0)

3 - 20 mm3

Go to product

Z-AC-4191802 Dosierventil AXDV-C1, 1 - 20 mm3 (V3.0)

Yes
pc
on request
Volumetric Metering Valve
AXDV-C1
1 - 20 mm3
up to NLGI class 3
200 bar
M5 / With Dispensing Tip Adapter LUER-Connection
R 1/8"
Standard
M2,5 for hose ø 4/2 mm
pneumatic/pressure controlled
Dosierventil AXDV-C1,

Dosierventil AXDV-C1,

1 - 20 mm3 (V3.0)

Go to product

Z-AC-4191803 Metering valve AXDV-C1 1 - 20 mm³, G1/8" (V3.0)

No
pc
on request
Volumetric Metering Valve
AXDV-C1-G1/8
1 - 20 mm3
up to NLGI class 3
200 bar
R 1/8" / With dosing needle adapter R 1/8''
R 1/8"
Standard
M2,5 for hose ø 4/2 mm
pneumatic/pressure controlled
Metering valve AXDV-C1

Metering valve AXDV-C1

1 - 20 mm³, G1/8" (V3.0)

Go to product

Z-AC-4191832 Metering valve AXDV-C1-PN 1 - 20 mm3 (V3.0)

No
pc
on request
Volumetric Metering Valve
AXDV-C1-PN
1 - 20 mm3
up to NLGI class 3
200 bar
M5 / With Dispensing Tip Adapter LUER-Connection
M8x1 / Plug connection
Handgrip PEN
M3 for hose ø 4/2 mm
pneumatic/pressure controlled
Metering valve AXDV-C1-PN

Metering valve AXDV-C1-PN

1 - 20 mm3 (V3.0)

Go to product

The listed prices are without VAT and apply to the quantity that is currently in stock
