Spark traps

Spark separators – Spark line – are mechanical devices designed to capture sparks and hot particles extracted from industrial processes.

They are equipped with integrated blades that induce rotation of the hot particles and sparks. During rotation, the particles collide with the blades, where they are mechanically extinguished.
Residual dust is collected by gravity into a container located beneath the separator.

We manufacture spark separators in both carbon steel and stainless steel versions.

Applications:

  • mechanical industry
  • automotive

Separation capacity:

  • 320 - 44 500 m3/h



Product range

Type Capacity
(m3/h)
Dust container
(l)
Diameter
(mm)

Spark 80 320 15 80
Spark 100 500 15 100
Spark 125 800 15 125
Spark 150 1 250 15 150
Spark 180 1 650 15 180
Spark 200 2 000 15 200
Spark 225 2 600 15 225
Spark 250 3 200 15 250
Spark 280 4 000 15 280
Spark 300 4 300 15 300
Spark 315 4 500 15 315
Spark 355 7 000 15 355
Spark 400 8 000 15 400
Spark 450 10 000 15 450
Spark 500 13 000 15 500
Spark 560 16 000 15 560
Spark 630 20 000 15 630
Spark 710 26 000 15 710
Spark 800 33 000 15 800
Spark 900 40 000 15 900
Spark 1000 44 500 15 1000

*
